类别Category |
车台天线 MobileAntennas |
|
型号Model |
TQC-1800A TQC-1800AI TQC-1800AII TQC-1800CI TQC- I800CII TQC-1800E TQC-1800T
|
|
频率范围Frequency Range-MHZ |
1710- 1990
|
|
带宽Bandwidth-MHZ |
170 |
|
增益Gain-dBi |
2.15 3.5 5 7 7 3 3
|
|
电压驻波比VSWR |
≤1.5 |
|
标称阻抗Nominal Impedance-Ω |
50 |
|
极化方式Polarization |
垂直vertical |
|
最大功率Maximum Power-W |
50 50 50 100 100 30 30
|
|
尺寸Dimensions-cm |
8 20 28 30 40 10 10
|
|
重量Weight-g |
100 140 150 220 250 100 100
|
|
接头型号Connector |
SMA 头或客户指定 SMA male or custon11zat1on
|
|
备注
Remarks
|
吸盘安装 车玻璃上粘贴安装 Matches with magnetic mount Stick on the glass of vehical |
佛山市华融通天线有限公司
Foshan Huarongtong Antenna Co., Ltd.
