Catcgory 类别

Panel Antennas 板状天线

Model 型号

TDJ-5800BKD23x2

 Frequency Range频率-MHz

5725~5850

 Bandwidth带宽-MHz

125

Gain增益-dBi

23x2

Horizontal Beanwidth水平角度-°

9

Vertical Beamwidth垂直角度-°

12

F/B Ratio前后比-dB

≥25

VSWR驻波

≤1.5

Nominal Impedance阻抗-Ω

50

Polarization极化方式

Vertical +horizontal

Maximum Power最大功率-W

100

Dimensions尺寸-mm

340X340X25

Weight重量-kg

2

Connector接头

N Female

MountingMast Diameter支撑杆直径-mm

Φ40~50
